Brief introduction:
Our liquid nitrogen dewar tank is an economical and practical liquid nitrogen storage solution specifically designed for the breeding industry. It is primarily intended for long-term static storage of frozen semen and convenient sampling.
Constructed from high-quality aviation-grade aluminum, this series features multiple layers of ultra-strong thermal insulation. This advanced design achieves a low liquid nitrogen evaporation rate, ensuring safe, lightweight, and efficient sample storage. The smaller liquid nitrogen tanks are particularly suitable for users who manually transfer and preserve biological samples, especially those in mountainous areas.
Features:
1. High vacuum multi-layer insulation design--low daily static evaporation rate of liquid nitrogen
2. Made of high-strength aviation aluminum--compact size, light weight, ease of portability
3. Have a special shock structure, strong and durable.
4. Numbered canisters for easy identification and independent access to samples.
5. Equipped with a protective bag to avoid product bumps.
6. Optional lock cover to protect the safety of stored samples.
Specification:
| Model | Volume (L) | Caliber (mm) | O.D (mm) | Height (mm) | Static Power Dissipation (D) | Static Storage (L/day) |
| YDS-10B | 10.48 | 50 | 334 | 565 | 52 | 0.2 |
| YDS-15B | 16.40 | 50 | 385 | 600 | 82 | 0.2 |
| YDS-20B | 21.45 | 50 | 385 | 660 | 107 | 0.2 |
| YDS-30B | 31.50 | 50 | 440 | 720 | 158 | 0.2 |
| YDS-35B | 35.20 | 50 | 440 | 720 | 176 | 0.2 |
| YDS-50B | 52.10 | 50 | 516 | 790 | 217 | 0.24 |
| YDS-50B-80 | 52.10 | 80 | 516 | 790 | 162 | 0.32 |
| YDS-50B-125 | 52.10 | 130 | 516 | 790 | 115 | 0.45 |
| YDS-50B-210 | 52.10 | 216 | 516 | 790 | 70 | 0.73 |
Application:
Our nitrogen tank is widely used not only in the storage of frozen semen, vaccines, cells, and microorganisms in the animal husbandry industry but also in various other fields such as machinery manufacturing, electronics, metallurgy, and energy.
